Galvanized Or Pvc Coated Gabion Cage Retaining Wall Horizontal Double Twisted Hexagonal Wire Mesh

Hebei KN Wire Mesh Co., Ltd.
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now

Galvanized Or Pvc Coated Gabion Cage Retaining Wall Horizontal Double Twisted Hexagonal Wire Mesh

Brand Name : KN

Model Number : Gabion Retaining walls

Certification : ISO CE

Place of Origin : CHINA

MOQ : 100pc

Price : USD 16-20

Payment Terms : L/C,D/A,D/P,T/T,Western Union,MoneyGram

Supply Ability : 5000m2 per day

Delivery Time : 7-8 days

Packaging Details : pallets Gabion Retaining walls

Surface Treatment : Hot-dipped Galvanized, Galfan Coated

Mesh Size : 60x80mm, 80x100mm, 100x120mm

Wire Diameter : 2.0-4.0mm

Features : Flexible, Durable, Easy to Install

Material : Galvanized Steel Wire

Tie Wire : 2.2mm

Application : Erosion Control, Slope Stabilization, Riverbank Protection

Tensile Strength : 350-500N/mm2

Color : Silver or Green

Selvedge Wire : 3.4mm

Zinc Coating : 240-290g/m2

Size : 2x1x1m, 3x1x1m, 4x1x1m, or customized

Unit Weight : 2.0-4.0kg/m2

Packing : Packed in bundles or on pallets Gabion Retaining walls

Lacing Wire : 2.2mm

Contact Now

galvanized or pvc coated Horizontal Double Twisted Hexagonal Wire Mesh Gabion Retaining walls

Durability:
Galvanized or PVC-coated metal wires are corrosion-resistant. protection wall

Galvanized Or Pvc Coated Gabion Cage Retaining Wall Horizontal Double Twisted Hexagonal Wire Mesh

Specification
Product Name
Gabion
Hole Type Hexagonal
Production process Three twist / Five twist
Material GI wire,PVC coated wire,galfan wire
Wire Diameter 2.0mm-4.0mm
Hole Size 60×80mm,80×100mm,100×120mm,120×150mm
Gabion Size

2m×1m×0.5m,2m×1m×1m,3m×1m×0.5m,3m×1m×1m4m×1m×0.5m,

4m×1m×1m,Other sizes can be customized.

Key Features and Benefits

1. economy. Just put the stone into the cage and seal it. 2. The construction is simple without special technology.
3. It has a strong ability to resist natural damage, corrosion resistance and adverse climate impact.
4. It can withstand large-scale deformation without collapse.
5. The silt between the stone gaps of the cage is conducive to plant production and can be melted into one with the surrounding
natural environment.
6. It has good permeability and can prevent damage caused by hydrostatic force. Conducive to the stability of hillside and beach
7. Save transportation cost, fold it up for transportation and assemble it on the construction site. 8. Good flexibility: no
structural joint, the overall structure has ductility.
9. Corrosion resistance : galvanized materials are not afraid of seawater.
10. Environmental protection materials: cadmium (CD) < 10ppm, lead (PB) < 50ppm,
other harmful substances such as mercury (Hg), hexavalent chromium (Cr6 +), PBB and PBDE are not detected, which fully meet the environmental protection standards of Rosh.

Galvanized Or Pvc Coated Gabion Cage Retaining Wall Horizontal Double Twisted Hexagonal Wire Mesh


Applications
Our gabion mattresses are widely used in various applications, including:
Erosion Control: Stabilizing soil and preventing erosion in riverbanks, coastal areas, and slopes.
Slope Stabilization: Reinforcing steep slopes and embankments to reduce the risk of landslides and soil instability.
Channel Lining and Bank Protection: Serving as durable linings for channels and culverts, preventing scouring and enhancing hydraulic performance.
Landscaping and Aesthetic Enhancement: Adding texture and visual interest to outdoor spaces while blending harmoniously with natural surroundings.


Manufacturing Excellence
As the largest manufacturer in China, we have state-of-the-art production facilities and advanced technology to ensure the highest quality standards. Our factory is ISO-certified, and we provide SGS test reports to guarantee the reliability and durability of our products. We also adhere to international standards such as ASTM A974 and ASTM A641.


Galvanized Or Pvc Coated Gabion Cage Retaining Wall Horizontal Double Twisted Hexagonal Wire Mesh
